Finder Relay — Miniature Power Relay (12 A, Plug-In)

Easy, Reliable Electrical Relay for Everyday Projects

This Finder relay makes it simple to switch household-level loads safely and reliably. It’s a compact, easy-to-use control relay you can plug into a matching socket, ideal for home automation, DIY electronics, hobby builds, and general switching tasks. Short on space? Its small footprint fits neatly in junction boxes and control panels.

Plug-In Relay Convenience with Dual Changeover Contacts

With 2-pole changeover (DPDT/CO) contacts rated up to 12 A and 250 V AC, this miniature power relay handles lights, fans, pumps, and other appliances with confidence. The plug-in socket design speeds installation and service—no soldering on the relay body required.

Why Choose a Finder Control Relay?

Simple to use: Plug-in mounting on matching 96 Series sockets; optional flange mount adaptor available.
Clear feedback: Optional lockable test button, mechanical position indicator, and double LED (DC non-polarized) for quick status checks.
Built for real-world duty: Up to 100,000 electrical cycles and a wide –40 °C to +70 °C ambient range.
Strong isolation: 4 kV insulation (coil to contacts) enhances safety.
Compact size: Only 20.7 × 37.2 × 27.7 mm—easy to fit in tight spaces.

Key Technical Specs (Finder Miniature Power Relay 12 A)

Contact configuration	2 pole, changeover (CO / nPDT / DPDT)
Rated contact voltage	250 V AC
Rated current (per pole)	12 A
Coil type / supply	DC coil, 6 V DC
Coil resistance / power	≈ 40 Ω, 1 W (typ.)
Coil current (nominal)	≈ 150 mA at 6 V DC
Must drop-out / holding voltage	≈ 0.6 V / 3.6 V
Electrical life	Up to 100,000 cycles
Insulation (coil/contacts)	4 kV
Ambient temperature	–40 °C to +70 °C
Contact material	AgNi
Dimensions (W × L × H)	20.7 × 37.2 × 27.7 mm
Mounting	Plug-in on 96 Series sockets; optional flange adaptor
Terminations (adaptor)	Faston 187 (4.8 × 0.5 mm)
Options	Lockable test button, mechanical indicator, double LED (DC non-polarized)

Where This Miniature Power Relay Fits

Use this Finder relay as a safe, dependable electrical relay in small control boxes, smart-home projects, or benchtop builds. Pair the 6 V DC coil with a low-voltage driver circuit (e.g., a transistor or relay module) and let the 12 A contacts do the heavy lifting on the load side. For the easiest setup, choose a matching plug-in relay socket from the 96 Series.

Model & Identification

Series: Finder 56 (Type 56.32) | Product code: 563290060070 (include this code when checking compatibility or ordering accessories).

Note: Specifications above summarize the official technical data for this specific model and its available options.
