PNP Darlington Transistor – 100V 12A Power Solution

Easy-to-Use High-Power PNP Darlington Transistor

Looking for a reliable high-current, high-voltage transistor for your projects? The PNP Darlington Transistor (NTE248) is a powerful solution ideal for anyone building or repairing audio amplifiers, power switching circuits, or motor controls. With its simple installation and strong performance, this silicon PNP Darlington transistor offers an excellent choice for beginners and experienced hobbyists alike.

Key Features & Benefits

• High Voltage & Current: Rated for up to 100 volts and 12 amps, suitable for demanding power applications.
• High Current Gain: Darlington configuration provides a typical DC gain (hFE) of 3500 for efficient switching and amplification.
• TO-3 Package: Durable metal case helps with heat dissipation and is widely used for easy mounting and reliability.
• Versatile Use: Perfect as a power amplifier transistor, power switching transistor, or in high output drivers.
• Complement to NTE247: Matches well with the NTE247 NPN Darlington transistor for high-quality, push-pull designs.
• Single Pack: Comes one per package for your convenience.

Technical Specifications

• Type: Silicon PNP Darlington Transistor
• Maximum Voltage (V_CEO): 100V
• Collector Current (I_C Max): 12A
• DC Current Gain (hFE): 3500 (typical)
• Package: TO-3 Metal Case
• Quantity Per Package: 1
• Original Part Number: NTE248

Simple, Reliable Performance

This high-power PNP Darlington transistor is trusted for its reliability and ease of use. For applications where you need dependable power handling and high gain, this component is an excellent fit. Whether you're upgrading an old amplifier, designing a new power supply, or working on a custom electronics project, you’ll appreciate the solid performance and straightforward installation.

Shop High-Performance Transistors at Vetco

Vetco Electronics offers a wide range of high-quality PNP and NPN Darlington transistors for every level of user. If you have questions about selecting the right power transistor or want to know more about matching the NTE248 to your circuit, our knowledgeable team is here to help. Enjoy fast shipping and friendly support for all your electronic project needs!

This part is the equivalent replacement for the following:

02064-5, 02064-5A, 02064-6, 02064-7, 02064-8, 1853-0391, 1853-0543, 2064-5, 2064-5(FISHER), 2064-6, 2064-6(FISHER), 2064-7, 2064-7(FISHER), 2064-8, 2064-9, 2064-9(FISHER), 2N3714HS, 2N6050, 2N6051, 2N6052, 2SB587, 2SB588, 2SB589, 2SB638, 2SB638H, 2SB639, 2SB639H, 2SC1954, 2SC810, 35C0735, 4822-130-40998, 482213040998, 4822-130-41031, 482213041031, 860051832, 9331-974-30112, 933197430112, 9331-974-40112, 933197440112, A1045(TRANS), B638, B638H, B639, B639H, BDX64, BDX64A, BDX64B, BDX86, BDX86A, BDX86B, BDX86C, BDX88, BDX88A, BDX88B, BDX88C, ECG248, GE-358, GT8100, GT8101, GT8102, GT8103, HEP-S9149, NTE248, PMD11K100, PMD11K40, PMD11K60, PMD11K80, PMD13K100, PMD13K40, PMD13K60, PMD13K80, SE9405, SJ1903, SJ2087, SK3949, SK3949/248, ST645, ST646, ST647, T1P605, T1P606, T1P607, TIP605, TIP606, TIP607, TIP645 (Minor electrical difference exists, but device will function in most applications.), TIP646 (Minor electrical difference exists, but device will function in most applications.), TIP647 (Minor electrical difference exists, but device will function in most applications.), TM248, TR0-2064-5, TR02064-5, TR0-2064-6, TR02064-6, TR0-2064-7, TR02064-7, TR0-2064-8, TR02064-9, WEP977
